Self-cleaning Filter

Introduction

The automatic self-cleaning filter is a precision device that uses a filter screen to directly intercept impurities in the water to purify the water quality and protect the normal operation of other equipment in the system. Water enters the self-cleaning filter body from the water inlet. Because of the intelligent (PLC, PAC) design, the system can automatically identify the degree of impurity deposition and send a signal to the drain valve to automatically drain the filter.

The automatic self-cleaning filter overcomes many shortcomings of traditional filtration products such as small dirt holding capacity, easy to be blocked by dirt, the filter part needs to be disassembled and cleaned, and the filter status cannot be monitored. It can filter raw water and automatically clean and discharge the filter element. function. Moreover, the system provides uninterrupted water supply during cleaning and sewage discharge, and can monitor the working status of the filter, with a high degree of automation. Covering various filtration precision requirements from 50um to 5000um, we provide customers with various water filtration equipment.

Features

1. Simple design structure.

2. Short back-cleaning time, large flow rate, and small pressure loss (≤ 0.018MPa).

3. Self-cleaning control methods are divided into pressure difference, time and manual.

4. The filter can be connected to the DCS system.

5. High-precision filtration, stable effluent quality, and sewage water consumption <1%.

6. No need to replace the filter screen.

7. Long service life.

8. Applicable to different raw water quality and water requirements.

9. Few wearing parts, no consumables, low operating costs, and simple operation and management.

10. Automatic backwashing and continuous flow.

Structure

Application

Raw water treatment

Cooling water treatment

Paper industry

Textile industry

Power industry

Agricultural irrigation

Vertical Self-cleaning Filter

Features:

Side water inlet

Side water outlet

Bottom sewage discharge

Application:

Metallurgy: continuous casting water, high-pressure phosphorus removal water, purification water, cooling water full filtration, side filtration, nozzle protection, etc.

Electric power: turbine cooling water filtration, wet electrostatic precipitator circulation gray water filtration, dust nozzle protection, cooling tower water full filtration and side filtration.

Agriculture: sprinkler irrigation, drip irrigation water treatment.

Horizontal Self-cleaning Filter

Features:

Bottom water inlet

Bottom water outlet

Side sewage discharge

Application:

Steel, Petroleum, Chemical Industry, Electronics, Textile, Papermaking, Food, Pharmaceutical, Automobile Industry, etc.

Multi-column Self-cleaning Filter

There are multiple filter cartridges inside.

Features:

Bottom water inlet

Side water outlet

Bottom sewage discharge

Application:

Metallurgical industry: filtering particulate impurities in water systems such as heavy metal scrap cleaning and recycling washing water, cooling circulating water, condensate water, etc., and protecting nozzles and water pumps.

Chemical and petrochemical industries: filter impurity particles in brine, industrial water, and circulating cooling water systems, and purify chemical media.

Power plants and thermal power plants: filter impurity particles in wet electrostatic precipitator sprays, spray circulation gray water, condensate water, and desulfurization wastewater systems, purify water quality, and protect nozzles and water pumps.

Oilfield wastewater: Filter suspended solids in oilfield wastewater to ensure the quality of return water.

Suction Self-cleaning Filter

Structure

1. Water inlet

2. Coarse filter

3. Fine filter

4. Backwash valve

5. Backwash chamber

6. Sewage suction pipe

7. Suction nozzle

8. Electric motor

9. Emergency backwash valve

10. Water outlet

Application:

Cooling towers

Supplementary water systems

Air conditioning systems

DC system water filtration

Raw water filtration

Seawater

Groundwater filtration

Industrial circulating water filtration

Agricultural irrigation

Paper industry water filtration
